283X-7090X Trinocular Compound Lab Microscope 25 Million Pixels USB3.0 Camera

Model KP-PH2500 Optical Magnification 40X-1600X Electronic Amplification 283X-7090X Observation Tube Hinge Trinocular,30 Degrees Inclined,360 Degrees Rotate Interpupillary Distance Adjustment Range 48mm-76mm Eyepiece Wide-angle Eyepiece WF10X/20mm,WF16 Objective Lens Infinite Flat Field Achromatic Objective PIan 4/0.1 PIan 10/0.25 PIan 40/0.65 PIan 100/1.25 oil Converter Four Holes Conversion Operating Platform Right Hand Low Hand Control of X and Y Directions Platform Area:160mmX142mm,Moving Range 76mmX52mm Coarse Micro Focusing Mechanism Low Hand Coarse Micro Coaxial Focusing Mechanism,Coarse Adjustment Stroke 22mm,Fine Adjustment Accuracy 0.002mm Condenser Abbe Condenser,N.A. = 1.25,Adjustable Center,With Variable Light bar and Filter Bracket Light Source Reflector Lamp Room,Single High Power 3W LED Power External Regulated Power Adapter, 100V-250V_AC50/60Hz DC5V/2A Trinocular Interface 1X Pixel 25 Million Pixels Output Method USB3.0 Sensor 25M IMX511(C) Sensor Size 1/2.3" (5.519x5.519) Resolution Frame Rate 12@4928x4928，46@2464x2464，100@1648x1648 Pixel Size 1.12μmx1.12μm Exposure Time 0.013ms~15s Exposure Auto/Manual White Balance ROI White Balance/ Manual Temp-Tint Adjustment Color Rendering Technique Ultra Fine Color Engine Capture/Control SDK Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++,C#/VB.NET,Python, Java,DirectShow,Twain,etc); Shooting Mode Images and Videos Operating System Microsoft Windows /Vista / 7 /8 /10(32 & 64 bit) OS X (Mac OS X),Linux File Save Can Set File Name,Save Pictures With Time Format,Save Path Selection Image Adjustment Hue,Saturation,Brightness,Contrast,Sharpness,Color,Grayscale Measuring Function Point Spacing,Point Line Spacing,Line Spacing,Center Distance arc,circle, Angle,Rectangle,Polygon Measurement,Calibration Function. Camera Function Advanced software for Windows: - SDK Available - Provides Stitching,EDF,Video Recording and Measurement Functions - Measurement of Length,Angle,Radian,area,etc. - Save Still Images in BMP,TIFF,JPG,PICT,PTL or other Formats - Edit and Process microscope images in a manner similar to PhotoShop  Packing List: 1、Eyepiece WF10X/20mm *2 2、Eyepiece WF16X *2 3、Objective Lens 4X *1 4、Objective Lens 10X *1 5、Objective Lens 40X *1 6、Objective Lens 100X *1 7、Trinocular Microscope Body *1 8、Power Adapter *1 9、5 Pieces Specimen *1 10、Dust Cover *1 11、25MP Camera *1 12、1.8m USB Cable *1 13、CD Software *1 14、Calibrating Ruler *1

• This Product Does Not Contain Computer.
• This Product is Through the USB Interface Connected to the Computer for Use,We Provide Free Professional Image Software.
